NANO E
How It Works
Modular and Semi-modular
To use NANO E with a modular or semi-modular system, connect a CV source to the IN/OUT socket and the OUT socket to the CV destination.
A steady voltage is usually desirable as the CV source, so pitch CV works well for this. Alternatively, you can get the voltage from a standard 9V center-negative guitar pedal power supply by using a Truetone C35 converter.
Expression Pedal
To connect NANO E to the expression pedal port on a regular synthesizer, simply use a 1/8” TRS to 1/4” TRS cable with the small end plugged into the socket market IN/OUT.
Note that the expression pedal ports on some synthesizers use the reverse polarity to the common standard for which NANO E is designed. In such cases, an RCA to TRS adapter and cable can be used to switch the polarity for normal operation.
Slider Replacement
The slider on NANO E can be easily replaced, if necessary.
One spare B100K slider and premium dust cover are included, along with a tool to complete the simple job.
